SMC2S Heavy Case Digital Industrial Thermometer Bimetallic Thermometer For Corrosive Media
Application
All stainless steel thermometer.Suitable for corrosive media and environments in chemical
process,petroleum and food industry. The instruments meet the highest standards of
measurement technique.
Features
Accuracy class 1.0, Quick response and high accuracy
External micro adjustment device, All stainless steel material
Hermetically sealed case structure, Temperature range up to 600℃(1100°F)
Standard dial dual unit ranges(°F & ℃), Sensor length up to 1000mm
Sensor diameter 6(standard),6.3,8 or 10mm
Technical Specification
Nominal Size : 21/2",3",4",5"and 6"
Accuracy Class : Class 1.0
Ingress Protection. : IP65
Connection Size : Fixed connection or Sliding connection, Size G1/4",G1/2" or NPT
Temperature Scale Range : -40° ..+600℃(-40° ..+100°F)
Sensing Element : Coiled bimetal sensing
Filling : Dry, but Fillable Silicone oil
Operating Temperature : Ambient temperature -50° ..+120℃
Bezel Ring Type : Bayonet case sealed, Exlernal calibralion device on back case
Dial Graduation : Standard in dual ranges °F and ℃
Design Material
Casing and Bezel Ring : SS304
Probe/bulb Sensor : SS316L
Connection : Stainless steel 304, sliding connection, or * Fixed welded connection
Window : Plain instrement glass
Pointer : Black painted aluminium
Dial Plate : Aluminium alloy, bowl cuppied type
Why choose us
1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
